Flatten Hemming Lower Die

1、The mold support plays a key supporting and protective role in the bending machine mold.

2 、Its main functions include: Support the upper mold: ensure the stable operation of the upper mold during the bending process to avoid mold damage or safety accidents caused by unstable movement of the upper mold.

3、Protect the mold: Prevent damage to the mold due to lifting of the sheet or other external factors during the bending process.

Send Inquiry

Description

Descriptions

Reasonable mold support design can improve bending efficiency and ensure the smooth progress of the bending process.
At the same time, the mold support can also help maintain the shape of the product after bending and improve the overall quality of the product.

Key attributes

Industry-specific attributes

Shaping Mode

Punching Mold

Other attributes

Place of Origin	Anhui, China
Brand Name	MIHARTING
Model Number	Customized
Product Material	Steel
Product	Press Brake Machine
Fitted Machine	Press Brake Machine
Optional Material	42CrMo/55SiCr/GCr15
Optional Hardness	45~52HRC
Supply Ability	800 Pieces/Month
Delivery Time	20-30days
Package	Wooden Box

Specifications

Common bending machine model	Dimensions of upper mold(mm)	Dimensions of lower mold(mm)
40T/2000	2000 * 70 * 18	2000 * 55 * 55
40T/2000	2000 * 80 * 18	2000 * 75 * 75
40T/2000	2000 * 90 * 30	2000 * 55 * 55
40T/2000	2000 * 150 * 26	2000 * 55 * 50
63T/2500	2000 * 85 * 28	2000 * 70 * 70
63T/2500	2500 * 150 * 25	2500 * 65 * 65
63T/2500	2500 * 85 * 28	2500 * 55 * 55
63T/2500	2500 * 100 * 20.5	2500 * 70 * 70
80T/3200	3200 * 80 * 18	3200 * 95 * 95
100T/3200	3200 * 150 * 26	3200 * 95 * 95
100T/3200	3250 * 86 * 28	3250 * 75 * 75
100T/3200	3200 * 72 * 30	3200 * 100 * 100
100T/3200	3250 * 80 * 25	3200 * 95 * 95
160T/3200	3250 * 90 * 56	3250 * 110 * 110
160T/4000	4000 * 80 * 25	3250 * 110 * 110
160T/4000	4000 * 90 * 30	3250 * 110 * 110
160T/4000	4000 * 134 * 34	3250 * 120 * 120
